- Size: 30
- Place of Origin: China
- Brand Name: heli
- Model Number: HL150
- Weight: 150.000 kg
- :
- :
- :
1)Adopt German technology, all core parts are imported, the laser usage life up to 100000 hours.
2)needn't water cooling device, smaller volume, convenient installation; free Maintenance.
3)work is stable and reliable; No consumables, low power consumption energy –saving.
4)Beam quality is wonderful, mark is clear and fine
5)It is with irreplaceable advantage in the field where need high requirements for the processing's depth, smoothness and precision
(e.g. mold industry, the bitmap marking industry).
- Size: 30
- Place of Origin: China
- Brand Name: heli
- Model Number: HL150
- Weight: 150.000 kg
- :
- :
- :
Model | HL-FB-10A/20A/30A |
Marking area | 100*100mm 150*150mm |
Laser power | 10W 20W 30w |
Laser type | fiber laser tube |
Engraving speed | 12000mm/s |
Colling model | Air cooling |
Power supply | 220V±10% /50HZ , 110V±10%//60HZ |
Min line width | 0.02mm |
Graphic format supported | BMP, PLT, DST, DXF, AI,CDR |
Software supported | CorelDraw, PhotoShop, AutoCAD |
Laser Output Control | 1-100% software setting |
Laser wavelength | 1064nm |
Color | Gray |
Machine size | 1188*600*1320mm |
Machine power | <250w |
Operating humidity | 5%-95%(without condensed water) |
Moving syestem | CNC
|
Laser life usage | 10,0000 hours |
Optional parts | Rotary device,Conveyor |
